    HMC1082 picture
    HMC1082
    Best Price NOW
    Amplifiers IC
    Manufacturer / Brand: AD
    Details: 5.5 GHz to 18 GHz, GaAs, pHEMT, MMIC, Medium Power Amplifier
    Series: HMC1082
    Quantity Available: Over 68830 pieces
    Our Email: [email protected]

    Datasheet for HMC1082:

    HMC1082 datasheet
    Price for HMC1082
    Product Parameters
    • Manufacturer Part Number : HMC1082
    • Manufacturer : AD
    • Description : 5.5 GHz to 18 GHz, GaAs, pHEMT, MMIC, Medium Power Amplifier
    • Series : HMC1082
    • Reference Price : USD 0
    • Our Price : We have a better price, contact us by email
    • Product Type : RF Amplifiers
    • Function : Driver Amplifiers
    • Current Suggest : Recommended for New Designs
    • Status : Production
    • RoHS Status: -
    • Voltage: -
    • Feature: -
    • Package Case: -
    • Temperature Range: -
    • Packing: Reel/Tray/Tube
    • Standard Packing Quantity: -
    • Country of Origin: -
    • Other Part Number : HMC1082
    • Shipping methods : DHL FEDEX UPS TNT
    • Delivery Time : Ship within 1 day.
    • Manufacturer Production time : 6-8 weeks (Normally have stocks)
    • Weight : 0.001KG

    Contact us to check the best price and real time inventory quantity for HMC1082. If you need any more information about HMC1082, you can also send us by email. Our email is [email protected], we will reply you in 12 hours.

    Request Quotation for HMC1082
    Part Number (*) Quantity (*) Target Price ($)
    Your Contact Information
    Company(*) Country(*)
    Name(*) Email(*)
    Message:
    ATTN: You can send us by email: [email protected] (We will reply quickly)
    Related IC Components
    Features and Benefits of HMC1082
    5.5 GHz to 18 GHz, GaAs, pHEMT, MMIC, Medium Power Amplifier
    Data Sheet
    Rev. A
    icon-recommended Recommended for New Designs
    Top
    Datasheet
    Data Sheet Rev. A
    2
    S-Parameters
    2 View All

    Overview

    Features and Benefits

    • High saturated output power: 26 dBm with 24% PAE
    • High gain: 24 dB typical
    • High output IP3: 36 dBm typical
    • High output P1dB: 25.5 dBm
    • Die size: 2.19 mm × 1.05 × 0.4 mm
    Product Detailed Description for HMC1082

    The HMC1082CHIP is a gallium arsenide (GaAs), monolithic microwave integrated circuit (MMIC), pseudomorphic high electron mobility transistor (pHEMT), driver amplifier that operates from 5.5 GHz to 18 GHz. The HMC1082CHIP provides a typical gain of 24 dB, 36 dBm output IP3, and 25.5 dBm of output power for 1 dB compression, requiring only 220 mA from a 5 V supply voltage. The saturated output power (PSAT) is 26 dBm with 24% power added efficiency (PAE).

    The HMC1082CHIP is an ideal driver amplifier for a wide range of applications including point to point radios from 5.5 GHz to 18 GHz and marine radars at 9 GHz. The HMC1082CHIP can also be used for 6 GHz to 18 GHz EW and ECM applications.

    Application

    • Software defined radios
    • Electronics warfare (EW)
    • Radar applications
    • Electronic countermeasures (ECMs)



    Lifecycle information of HMC1082

    This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
